Keeping Your Vacuum Excavator in Peak Winter Condition

When cold weather conditions set in, regular maintenance and a heightened awareness of how to keep vacuum excavation equipment operating properly is required to avoid costly repair expenses. There are thousands of vacuum excavators at work across North America, and a majority of these units are working through the winter in extremely cold conditions.

Winterizing Tips

It’s important to follow all winter maintenance recommendations as outlined in the operator’s manual. These will generally include the following items.

// ** Advertisement ** //

RELATED: How to Safely Handle Hose

  • Check coolant and use recommended antifreeze/water mixture for the lowest temperature expected during operation.

  • Make sure the water heater works properly

  • Use hydraulic oil and lubricants designed for the cold weather.

  • Maintain the battery by removing and cleaning cables, cleaning cable ends and posts, and cleaning and tightening the terminals.

  • Change fuel filters routinely.

The service technicians at your equipment dealer can also provide helpful advice. Beyond the basic winter maintenance tips, TRUVAC offers some additional recommendations to keep your vacuum excavation equipment operating efficiently throughout the winter.

// ** Advertisement ** //

Cold Weather Truck Options

For vacuum excavators, digging in extremely cold temperatures or air excavation can provide the most stress on the equipment. Not all equipment is designed to operate in cold temperatures. TRUVAC vacuum excavation trucks are designed to operate efficiently in temperatures as low as –40 F (-25.5 C).

TRUVAC offers a number of cold weather options, including heated storage, heated water pump and water heater cabinets, toolbox heaters, and warming cabinets. TRUVAC vacuum excavators featuring the Kenworth T880 chassis can be equipped with an arctic package including a block and pan heater, heated fuel water separator, coolant tank heater, battery pad heater and arctic hose options for colder extremes.

// ** Advertisement ** //

It’s important to prevent the water system on your vacuum excavator from freezing. The TRUVAC HXX water tank is manufactured from HDPE which retains heat in the cold winter months better than steel or stainless-steel materials traditionally used in other equipment. The tank water can also be preheated through the onboard water heater that is capable of 800,000 BTUs. For extreme applications, the TRUVAC HXX is also available with a heated debris body to prevent excavated material from freezing up and greatly improving material offloading in the cold winter months.

Before, During and After the Job

  • Make sure all water lines are heated and insulated – including the water pump cabinet.

  • Allow hydraulic fluid and transmission fluid to warm up before operation.

  • Before heading out on the job, check airline hoses for cracking, and make sure the air dryer is functioning properly to prevent lines from freezing. Alcohol can be added to the system to prevent freezing.

  • Make sure all lights are operating and free of snow, ice and dirt.

  • Use a recirculator to circulate water through the water system during transport. Check the recirculator each day to ensure that it is operational.

  • If the telescoping boom is frozen and can’t be properly extended, retracted or cradled, insert a digging lance into the end of the boom and run low-pressure heated water to thaw any ice.

  • Keep tires inflated to the proper pressure rating. Tire pressure decreases over time, especially when winter temperatures fluctuate.

  • Regular washing of the truck, especially during the winter, will help prevent the buildup of salt and other corrosive material that can cause rust or wear.

  • When shutting down for the day, drain and purge all water – or run glycol through the line with a glycol injection system to keep water from freezing – especially if the vacuum excavator is parked outside in the cold at night. TRUVAC vacuum excavators feature an air purge option that uses chassis air to blow out the water line at the end of the day.

  • Some contractors and municipalities have indoor garages where they can park their vacuum excavators at night.

  • For any trucks parked outside overnight or for any extended period of time in the winter, block heaters should be used. The truck chassis can also be spec’d for cold weather options such as:

o Wind front on grill to maintain heat in the cold

o Battery heater

o Fuel line heaterw

o Arctic package

// ** Advertisement ** //

Visibility Is Important

For the safety of the operator – and any others on the jobsite, or on the road when traveling to and from the job – good visibility is essential. Keep the windshield wiper fluid tank full of a winter blend to prevent freezing and install winter weather wiper blades to help keep snow and ice off the windshield.

Proper lighting is also important for enhanced visibility, especially during the winter months when the days are shorter, and sunlight is minimal. When driving in snow, vacuum excavators and other vehicles can be hard to see, so it’s important to include additional DOT lighting on the truck beyond the standard DOT clearance lighting to increase visibility. Additional work lights should be installed on vacuum excavators to enhance visibility to the site when working in the early morning or evening hours and when working in snowy conditions. For added visibility and safety, operators should also wear reflective gear over their clothing.

// ** Advertisement ** //

RELATED: WWETT Show 2020 Preview – PROs Ready to Convene in Indy

Stay Warm and Productive

Human skin begins to freeze when the temperature drops below 32 F (0 C), resulting in frostbite. Exposure to extreme cold can also lead to hypothermia and trench foot. TRUVAC vacuum excavators feature optional warming cabinets to allow operators to warm up in cold weather.

// ** Advertisement ** //

Always Be Prepared

Depending on the job, a vacuum excavator operator might be working in very remote locations, far from the closest town. They might be facing steadily dropping temperatures, with snow and ice in the forecast. With this scenario in mind, TRUVAC recommends keeping an emergency survival kit in the truck that includes extra hats, gloves, gaiters and other winter clothing; blankets; food and water; flashlights; batteries; matches; emergency flares and first-aid kit.

Vacuum excavation equipment requires thorough maintenance to keep it running smoothly year-round, and especially during the winter months. Winterizing equipment – and taking the necessary steps before, during and after operating in winter conditions – ensures efficient performance and maximum uptime and protects your investment.

// ** Advertisement ** //

Nick Bruhn is a product manager at TRUVAC.
